Data Transfer

Last update: February 25, 2025

There are several transfer mechanism for data to Frontera, some of which depend on where and how the data are to be stored. Please review the following transfer mechanisms.

This guide will outline and instruct methods of transferring data between TACC resources and and your local machine. Transfer methods generally fall into two categories:

1. Command-line (CLI) tools e.g. scp, sftp, rsync
2. Graphical User Interface (GUI) tools, e.g. Globus, Cyberduck.

Determining Paths

Before beginning data transfer with command-line tools, you will need to know:

• the path to your data file(s) on your local system
• the path to your transfer directory on the remote system

In order to transfer your project data, you will first need to know where the files are located on your local system.

To do so, navigate to the location of the files on your computer. This can be accomplished on a Mac by using the Finder application or on Windows with File Explorer application. Common locations for user data at the user's home directory, the Desktop and My Documents.

Once you have identified the location of the files, you can right-click on them and select either Get Info (on Mac) or Properties (on Windows) to view the path location on your local system.

Figure 1. Use Get Info to determine "Where" the path of your data file(s) is

For example, a file located in a folder named portal-data under Documents would have the following path:

On Mac	/Users/username/Documents/portal-data/my_file.txt
On Windows	\Users\username\My Documents\portal-data\my_file.txt

GUI

Cyberduck

TACC staff recommends the open-source Cyberduck utility for both Windows and Mac users that do not already have a preferred tool.

Cyberduck is a free graphical user interface for data transfer and is an alternative to using the command line. With a drag-and-drop interface, it is easy to transfer a file from your local system to the remote secure system. You can use Cyberduck for Windows or macOS.

Download Cyberduck

Click on the "Open Connection" button in the top right corner of the Cyberduck window to open a connection configuration window (as shown below) transfer mechanism, and type in the server name "frontera.tacc.utexas.edu". Add your username and password in the spaces provided, and if the "more options" area is not shown click the small triangle or button to expand the window; this will allow you to enter the path to your project area so that when Cyberduck opens the connection you will immediately see your data. Then click the "Connect" button to open your connection.

Once installed, click "Open Connection" in the top left corner of your Cyberduck window.

Once connected, you can navigate through your remote file hierarchy using familiar graphical navigation techniques. You may also drag-and-drop files into and out of the Cyberduck window to transfer files to and from Frontera.

To set up a connection, type in the server name, host. Add your TACC username and password in the spaces provided. If the "More Options" area is not shown, click the small triangle button to expand the window; this will allow you to enter the path to your transfer directory, /transfer/directory/path, so that when Cyberduck opens the connection you will immediately be in your individualized transfer directory on the system. Click the "Connect" button to open your connection.

Once connected, you can navigate through your remote file hierarchy using the graphical user interface. You may also drag-and-drop files from your local computer into the Cyberduck window to transfer files to the system.

SSH Command-Line Tools

Introduce - scp, rsync, sftp Examples with Corral

A common method of transferring files between TACC resources and/or your local machine is through the command line. Whether on a Windows or a Mac, open the terminal applicaton on your local laptop to use one of the following Unix command-line (CLI) tools.

These three command line tools are secure and can be used to accomplish data transfer. You can run these commands directly from the terminal if your local system runs Linux or macOS: scp, sftp, & rsync

To simplify the data transfer process, we recommend that Windows users follow the How to Transfer Data with Cyberduck guide as detailed below.

The scp and rsync commands are standard UNIX data transfer mechanisms used to transfer moderate size files and data collections between systems. These applications use a single thread to transfer each file one at a time. The scp and rsync utilities are typically the best methods when transferring Gigabytes of data. For larger data transfers, parallel data transfer mechanisms, e.g., Grid Community Toolkit, can often improve total throughput and reliability.

Transfer files between TACC HPC resources and other Linux-based systems using either scp or rsync. Both scp and rsync are available in the Mac Terminal app. Windows SSH clients typically include scp-based file transfer capabilities.

scp section

The Linux scp (secure copy) utility is a component of the OpenSSH suite. Assuming your Lonestar6 username is bjones, a simple scp transfer that pushes a file named myfile from your local Linux system to Lonestar6 $HOME would look like this:

localhost$ scp ./myfile bjones@ls6.tacc.utexas.edu:  # note colon after net address

You can use wildcards, but you need to be careful about when and where you want wildcard expansion to occur. For example, to push all files ending in .txt from the current directory on your local machine to /work/01234/bjones/scripts on Lonestar6:

localhost$ scp *.txt bjones@ls6.tacc.utexas.edu:/work/01234/bjones/ls6

To delay wildcard expansion until reaching Lonestar6, use a backslash (\) as an escape character before the wildcard. For example, to pull all files ending in .txt from /work/01234/bjones/scripts on Lonestar6 to the current directory on your local system:

localhost$ scp bjones@ls6.tacc.utexas.edu:/work/01234/bjones/ls6/\*.txt .

You can of course use shell or environment variables in your calls to scp. For example:

localhost$ destdir="/work/01234/bjones/ls6/data"
localhost$ scp ./myfile bjones@ls6.tacc.utexas.edu:$destdir

You can also issue scp commands on your local client that use Lonestar6 environment variables like $HOME, $WORK, and $SCRATCH. To do so, use a backslash (\) as an escape character before the $; this ensures that expansion occurs after establishing the connection to Lonestar6:

localhost$ scp ./myfile bjones@ls6.tacc.utexas.edu:\$SCRATCH/data   # Note backslash

Avoid using scp for recursive transfers of directories that contain nested directories of many small files:

localhost$ scp -r ./mydata     bjones@ls6.tacc.utexas.edu:\$SCRATCH  # DON'T DO THIS

Instead, use tar to create an archive of the directory, then transfer the directory as a single file:

localhost$ tar cvf ./mydata.tar mydata                                  # create archive
localhost$ scp     ./mydata.tar bjones@ls6.tacc.utexas.edu:\$WORK  # transfer archive

--

The scp command copies files between hosts on a network. To transfer a file (ex. my_file.txt) to the remote secure system via scp, open a terminal on your local computer and navigate to the path where your data file is located.

On Mac	localhost$ cd ~/Documents/portal-data/
On Windows	localhost$ cd %HOMEPATH%\Documents\portal-data\

Assuming your TACC username is bjones and you are affiliated with UT Austin, a scp transfer that pushes my_file.txt from the current directory of your local computer to the remote secure system would look like this:

This command will copy your data file directly to your individualized transfer directory on the remote storage system.

localhost$ scp ./my_file.txt bjones@host:/transfer/directory/path

If you have not done so already, enter this command in your terminal, replacing the file name, TACC username, and your individualized transfer directory path appropriately.

After entering the command, you will be prompted to login to the remote secure system by entering the password associated with your TACC account as well as the token value generated from your TACC token app.

A successful data transfer will generate terminal output similar to this:

my_file.txt     100% ##  #.#          KB/s   ##:##g

--

Data transfer from any Linux system can be accomplished using the scp utility to copy data to and from the login node. A file can be copied from your local system to the remote server by using the command:

localhost% scp filename \
TACC-username@frontera.tacc.utexas.edu:/path/to/project/directory

Consult the scp man pages for more information:

login1$ man scp

rsync Section

Lonestar6 Transferring with rsync

The rsync (remote synchronization) utility is a great way to synchronize files that you maintain on more than one system: when you transfer files using rsync, the utility copies only the changed portions of individual files. As a result, rsync is especially efficient when you only need to update a small fraction of a large dataset. The basic syntax is similar to scp:

localhost$ rsync       mybigfile bjones@ls6.tacc.utexas.edu:\$SCRATCH/data
localhost$ rsync -avtr mybigdir  bjones@ls6.tacc.utexas.edu:\$SCRATCH/data

The options on the second transfer are typical and appropriate when synching a directory: this is a recursive update (-r) with verbose (-v) feedback; the synchronization preserves time stamps (-t) as well as symbolic links and other meta-data (-a). Because rsync only transfers changes, recursive updates with rsync may be less demanding than an equivalent recursive transfer with scp.

Frontera Transferring Files with rsync

The rsync (remote synchronization) utility is a great way to synchronize files that you maintain on more than one system: when you transfer files using rsync, the utility copies only the changed portions of individual files. As a result, rsync is especially efficient when you only need to update a small fraction of a large dataset. The basic syntax is similar to scp:

localhost$ rsync       mybigfile bjones@frontera.tacc.utexas.edu:\$WORK/data
localhost$ rsync -avtr mybigdir  bjones@frontera.tacc.utexas.edu:\$WORK/data

The options on the second transfer are typical and appropriate when synching a directory: this is a recursive update (-r) with verbose (-v) feedback; the synchronization preserves time stamps (-t) as well as symbolic links and other meta-data (-a). Because rsync only transfers changes, recursive updates with rsync may be less demanding than an equivalent recursive transfer with scp.

See Good Conduct for additional important advice about striping the receiving directory when transferring large files; watching your quota on $HOME and $WORK; and limiting the number of simultaneous transfers. Remember also that $STOCKYARD (and your $WORK directory on each TACC resource) is available from several other TACC systems: there's no need for scp when both the source and destination involve subdirectories of $STOCKYARD.

The rsync command is another way to keep your data up to date. In contrast to scp, rsync transfers only the actual changed parts of a file (instead of transferring an entire file). Hence, this selective method of data transfer can be much more efficient than scp. The following example demonstrates usage of the rsync command for transferring a file named myfile.c from its current location on Stampede to Frontera's $DATA directory.

login1$ rsync myfile.c \
TACC-username@frontera.tacc.utexas.edu:/data/01698/TACC-username/data

An entire directory can be transferred from source to destination by using rsync as well. For directory transfers the options -avtr will transfer the files recursively (-r option) along with the modification times (-t option) and in the archive mode (-a option) to preserve symbolic links, devices, attributes, permissions, ownerships, etc. The -v option (verbose) increases the amount of information displayed during any transfer. The following example demonstrates the usage of the -avtr options for transferring a directory named gauss from the present working directory on Stampede to a directory named data in the $WORK file system on Frontera.

login1$ rsync -avtr ./gauss \
TACC-username@frontera.tacc.utexas.edu:/data/01698/TACC-username/data

For more rsync options and command details, run the command rsync -h or:

login1$ man rsync

When executing multiple instantiations of scp or rsync, please limit your transfers to no more than 2-3 processes at a time.

Transfer with sftp

sftp is a file transfer program that allows you to interactively navigate between your local file system and the remote secure system. To transfer a file (ex. my_file.txt) to the remote secure system via sftp, open a terminal on your local computer and navigate to the path where your data file is located.

On Mac	localhost$ cd ~/Documents/portal-data/
On Windows	localhost$ cd %HOMEPATH%\Documents\portal-data\

Assuming your TACC username is bjones and you are affiliated with UT Austin, an sftp transfer that pushes my_file.txt from the current directory of your local computer to the remote secure system would look like this:

localhost$ sftp bjones@host:/transfer/directory/path
Password:
TACC Token Code:
Connected to host.
Changing to:
  /transfer/directory/path
sftp>

If you have not done so already, enter this command in your terminal, replacing the TACC username bjones and your individualized transfer directory path appropriately.

Once you've logged into the remote secure system and have been redirected to your transfer directory, confirm your location on the server:

sftp> pwd
Remote working directory:
/transfer/directory/path

To list the files currently in your transfer directory:

sftp> ls
utaustin_dir.txt

To list the files currently in your local directory:

sftp> lls
my_file.txt

To transfer my_file.txt from your local computer to your transfer directory:

sftp> put my_file.txt
Uploading my_file.txt to /transfer/directory/path
my_file.txt     100% ##  #.#          KB/s   ##:#

To check if my_file.txt is in the utaustin subfolder:

sftp> ls
my_file.txt
utaustin_dir.txt

To exit out of sftp on the terminal:

sftp> bye
localhost1$

If you wish to learn more about sftp, you can do so at the online man page for scp.

UTBox and other Third-Party Storage Services

Unfortunately TACC does not allow direct access from UT Box or other third-party storage services such as Dropbox, Google or Amazon storage services. To transfer files from one of these services:

1. Manually download the files from one of these services to your laptop
2. Using one of the tools outlined in this document (e.g. scp or Cyberduck), upload the files from your laptop to the desired TACC resource (e.g. Stampede3, Frontera).

If you have files stored at another university, see the Globus instructions above.

Corral

How to integrate Corral
